Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones

SKU: TAS-DR-701D
🏭 Available at Supplier This item is typically at our supplier’s warehouse and usually ships to you in 2-3 days. Place your order now, and we’ll ensure it’s dispatched to you as soon as it arrives.
Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones
Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones
Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones
Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones
Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones

Main Features

  • Linear PCM recorder that can record up to 6channels (4 channels + 2mix recording)
  • Meets the needs of professional users with HDMI sync function and time code input
  • Compact and rigid chassis made with magnesium alloy
  • Offers higher sound quality than DR-70D by choosing higher grade operational amplifier
  • 4 XLR/TRS Inputs with Phantom Power
  • Dual Built-In Omnidirectional Mics
  • Stereo 3.5mm In for Stereo Mic
  • 3.5mm Camera In/Out
  • BNC In for Sync to SMPTE
  • HDMI in Supports Start/Stop from DSLR
  • Writes Time Data to Recorded Audio Files
  • Records Up to 24-Bit/192kHz
  • Mount to DSLR or Tripod
The DR-701D is TASCAM's flagship recorder for single-shooter video production. A timecode generator is included for location reference, which can be jam synced from a SMPTE generator, camera, or smart slate. The HDMI in and out allows a...
More Details

Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones

SKU: TAS-DR-701D
🏭 Available at Supplier This item is typically at our supplier’s warehouse and usually ships to you in 2-3 days. Place your order now, and we’ll ensure it’s dispatched to you as soon as it arrives.
Fast Shipping
Secure payment
Tax Included
$899.00
🏭 Available at Supplier This item is typically at our supplier’s warehouse and usually ships to you in 2-3 days. Place your order now, and we’ll ensure it’s dispatched to you as soon as it arrives.
Tax Included
$899.00

4 x

$224.75

from

$10

4 x

$224.75
Tax included.

What's in the box

  • USB Cable
  • 6 x Camera Attachment Bracket Screw Hole Covers
  • 3 Years Warranty
Write a Review
Ask a Question

Main Features

  • Linear PCM recorder that can record up to 6channels (4 channels + 2mix recording)
  • Meets the needs of professional users with HDMI sync function and time code input
  • Compact and rigid chassis made with magnesium alloy
  • Offers higher sound quality than DR-70D by choosing higher grade operational amplifier
  • 4 XLR/TRS Inputs with Phantom Power
  • Dual Built-In Omnidirectional Mics
  • Stereo 3.5mm In for Stereo Mic
  • 3.5mm Camera In/Out
  • BNC In for Sync to SMPTE
  • HDMI in Supports Start/Stop from DSLR
  • Writes Time Data to Recorded Audio Files
  • Records Up to 24-Bit/192kHz
  • Mount to DSLR or Tripod
The DR-701D is TASCAM's flagship recorder for single-shooter video production. A timecode generator is included for location reference, which can be jam synced from a SMPTE generator, camera, or smart slate. The HDMI in and out allows a...
More Details

  • Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones

    The DR-701D is TASCAM's flagship recorder for single-shooter video production. A timecode generator is included for location reference, which can be jam synced from a SMPTE generator, camera, or smart slate. The HDMI in and out allows a DSLR camera to start recording on both devices, and video clock prevents drift between sound and picture.

    Four mic inputs can be individually recorded and mixed to a stereo track, for a total of six-track recording. For additional tracks, multiple units can be cascaded together. The lightweight yet rigid chassis is forged from a magnesium alloy. Tripod mounts on the top and bottom of the unit allow the unit to mount under a camera, attach to a follow-focus cage, or used stand-alone.

    Designed for the needs of professional filmmakers, television producers, advertisers, and documentarians, the DR-701D packs high quality multitrack recording into a package compact enough for use with any camera.

    Key Features

    • SD/SDHC/SDXC cards used for recording media.
    • 6 maximum simultaneous recording tracks
    • MONO, STEREO, 2MIX, DUAL MONO, DUAL ST and DUAL2MIX recording modes
    • Recording formats: 16/24-bit, 44.1/48/96/192kHz (WAV/BWF) (192kHz only for two-track recording)
    • Built-in original TASCAM HDDA mic preamps provide high audio quality
    • Input levels can be adjusted separately for each track
    • XLR/TRS inputs support +4dBu line level and 24/48V phantom power
    • Clock and record start/stop can be synchronized with a camera using the HDMI port
    • DR-701D audio signal can be output to an external camera or recorder from the HDMI OUT or line output
    • Cascade function using HDMI connections allows multiple DR-701D transport and monitoring operations
    • SMPTE Timecode can be input through the TC IN connector to add recording start times to files
    • Timecode generator (RTC) allows recording start times to be added to files even when there is no timecode input
    • Plug-in power mics and high output mics (EXT IN 1/2) supported
    • OUT (CAMERA OUT) connector can output audio mixed by the DR-701D to a DSLR camera
    • IN (CAMERA IN) connector enables monitoring the sound from a DSLR camera through the DR-701D
    • High quality audio output through a line output jack separate from the headphones jack
    • Headphones jack with 50mW+50mW maximum output
    • Tripod attachment threads (bottom), camera screw attachment that can be installed or removed with a coin (top) and shoe mount (top) included
    • Handles on the left and right sides of the front protect the control surface and also enable attachment of a shoulder strap
    • Transport and SLATE buttons made of rubber suppress noise during operation
    • HOLD switch prevents misoperation
    • 128×64-dot graphic LCD with backlight
    • LED lights have high visibility even in direct sunlight
    • High-speed transfer of files to computers possible using USB 2.0
    • Micro-B type USB cable included
    • Powered by 4 AA batteries, USB bus power or a PS-P515U AC adapter (sold separately)
    • BP-6AA external battery pack (sold separately) enables operation for even longer times
    • Optional RC-3F foot switch and RC-10 wireless remote control can be connected (both sold separately)
    • Built-in mixer enables pan and level adjustments as well as solo monitoring and can output a mix of 4 channels
    • GANG function allows the levels of multiple channels to be controlled simultaneously
    • Individual channel trim settings shown
    • 5-position low-cut filter (50/80/120/180/220 Hz) cuts unwanted low frequencies
    • Multiband limiter automatically adjusts input overloads (stereo-linking possible with 1/L and 2/R)
    • Delay function can compensate for distances between mics (+/-150 ms)
    • Mid-side decoder function enables use with mid-side stereo mics
    • Slate tone insertion functions (AUTO/MANUAL)
    • Slate tone insertion points can be selected (recording start or recording start and stop when slate AUTO function used)

Tascam DR-701D 4-Channel / 6-Track Multitrack Field Recorder with Onboard Omni Microphones

The DR-701D is TASCAM's flagship recorder for single-shooter video production. A timecode generator is included for location reference, which can be jam synced from a SMPTE generator, camera, or smart slate. The HDMI in and out allows a DSLR camera to start recording on both devices, and video clock prevents drift between sound and picture.

Four mic inputs can be individually recorded and mixed to a stereo track, for a total of six-track recording. For additional tracks, multiple units can be cascaded together. The lightweight yet rigid chassis is forged from a magnesium alloy. Tripod mounts on the top and bottom of the unit allow the unit to mount under a camera, attach to a follow-focus cage, or used stand-alone.

Designed for the needs of professional filmmakers, television producers, advertisers, and documentarians, the DR-701D packs high quality multitrack recording into a package compact enough for use with any camera.

Key Features

  • SD/SDHC/SDXC cards used for recording media.
  • 6 maximum simultaneous recording tracks
  • MONO, STEREO, 2MIX, DUAL MONO, DUAL ST and DUAL2MIX recording modes
  • Recording formats: 16/24-bit, 44.1/48/96/192kHz (WAV/BWF) (192kHz only for two-track recording)
  • Built-in original TASCAM HDDA mic preamps provide high audio quality
  • Input levels can be adjusted separately for each track
  • XLR/TRS inputs support +4dBu line level and 24/48V phantom power
  • Clock and record start/stop can be synchronized with a camera using the HDMI port
  • DR-701D audio signal can be output to an external camera or recorder from the HDMI OUT or line output
  • Cascade function using HDMI connections allows multiple DR-701D transport and monitoring operations
  • SMPTE Timecode can be input through the TC IN connector to add recording start times to files
  • Timecode generator (RTC) allows recording start times to be added to files even when there is no timecode input
  • Plug-in power mics and high output mics (EXT IN 1/2) supported
  • OUT (CAMERA OUT) connector can output audio mixed by the DR-701D to a DSLR camera
  • IN (CAMERA IN) connector enables monitoring the sound from a DSLR camera through the DR-701D
  • High quality audio output through a line output jack separate from the headphones jack
  • Headphones jack with 50mW+50mW maximum output
  • Tripod attachment threads (bottom), camera screw attachment that can be installed or removed with a coin (top) and shoe mount (top) included
  • Handles on the left and right sides of the front protect the control surface and also enable attachment of a shoulder strap
  • Transport and SLATE buttons made of rubber suppress noise during operation
  • HOLD switch prevents misoperation
  • 128×64-dot graphic LCD with backlight
  • LED lights have high visibility even in direct sunlight
  • High-speed transfer of files to computers possible using USB 2.0
  • Micro-B type USB cable included
  • Powered by 4 AA batteries, USB bus power or a PS-P515U AC adapter (sold separately)
  • BP-6AA external battery pack (sold separately) enables operation for even longer times
  • Optional RC-3F foot switch and RC-10 wireless remote control can be connected (both sold separately)
  • Built-in mixer enables pan and level adjustments as well as solo monitoring and can output a mix of 4 channels
  • GANG function allows the levels of multiple channels to be controlled simultaneously
  • Individual channel trim settings shown
  • 5-position low-cut filter (50/80/120/180/220 Hz) cuts unwanted low frequencies
  • Multiband limiter automatically adjusts input overloads (stereo-linking possible with 1/L and 2/R)
  • Delay function can compensate for distances between mics (+/-150 ms)
  • Mid-side decoder function enables use with mid-side stereo mics
  • Slate tone insertion functions (AUTO/MANUAL)
  • Slate tone insertion points can be selected (recording start or recording start and stop when slate AUTO function used)
