Panasonic 4K30 HDMI PTZ Camera with 24x Optical Zoom (Black)

Panasonic 4K30 HDMI PTZ Camera with 24x Optical Zoom (Black)

Bring UHD 4K quality video to your production with the black 4K30 HDMI PTZ Camera from Panasonic. This pro PTZ camera outputs up to UHD 4K30 over HDMI 1.4, and it supports IP live streaming up to 1080p to fit into any environment such as a conference room or classroom. The camera can also be used as a webcam with a built-in USB Type-C port. It features a large 1/2.5" MOS sensor, a 24x optical zoom with a wide 74.1° angle-of-view, and PoE+ compatibility for single-cable operation.

The camera supports embedded audio and audio input via a stereo mini-jack for embedding into your output stream. Its redesigned web interface is compatible with Windows and macOS computers as well as Android and iOS smartphones. Additional features include a red/green tally light, extended 28x UHD 4K digital zoom, extended 36x Full HD digital zoom, and live streaming via H.264/H.265 codecs. The camera can be remotely controlled via IP, RS-422, or via its USB Type-C port via UVC 1.0/UAC 1.0. The camera is upgradable to NDI/HX compatibility or subject tracking with separately available licenses.

Stable Environment for Online and Offline

• 4K resolution with wide-angle and high-magnification zoom for capturing all aspects of your room.
• Secure and stable streaming protocol for reduced risk of communication trouble.
• Smooth playback of high-quality videos.
• Optional auto-racking software is available for reliable following and capturing of the speaker.

Compact Size and Quiet Operation

• The compact dome-shaped design blends in with the surroundings. Its lightweight and small size give added flexibility in camera installation.
• Quiet operating sound allows the use of the camera in any situation.
• Integrated optical image stabilization ensures stable video shooting.

Flexibility for Smooth Operation

• Easy installation and operation, even for inexperienced staff or small staff.
• Single computer via USB or optional IP or serial controller can manage and control multiple cameras.
• The camera can be used as a USB webcam.
• The camera can stream video directly to a live streaming service.

Imaging

Sensor Type 1/2.5"-Type MOS Sensor

Horizontal Resolution (TV Lines) 1500 TV Lines

Sensor Resolution Effective: 8.49 Megapixel

Built-In ND Filter None

Image Stabilization Optical in Integrated Lens

Focus Control Autofocus Manual Focus

Exposure Control

Shutter Type Electronic Rolling Shutter

Shutter Speed 1/10000 to 1/25

Second Gain 0 to 36 dB (Native)

Minimum Illumination 3 Lux

Flip / Mirror Support Image Flip

White Balance 2000 to 15,000K

Lens

Focal Length 4.1 to 98.9mm (35mm Equivalent Focal Length: 25 to 600mm)

Optical Zoom Ratio 24x

Max Digital Zoom 36x ( in 1080p)

Field of View Horizontal: 74.1 to 3.3° Vertical: 46 to 1.9° Diagonal: 81.8 to 3.8°

Maximum Aperture f/1.8 to 4

Minimum Focus Distance Wide: 3.9" / 10.0 cm Telephoto: 47.2" / 120.0 cm

Video Capture

External Recording Modes

4:2:2 10-Bit via HDMI

3840 x 2160 at 23.98/24.00/25/29.97 fps

1920 x 1080p at 23.98/24.00/25/29.97/50/59.94 fps

1920 x 1080i at 50/59.94 fps

1280 x 720 at 50/59.94 fps

RJ45 / USB

1920 x 1080p at 25/29.97/50/59.94 fps

1280 x 720 at 25/29.97/50/59.94 fps

640 x 360 at 25/29.97/59.94 fps

320 x 180p at 25/29.97/50/59.94 fps

Audio Recording 2-Channel 16-Bit 48 kHz AAC LC Audio

Broadcast Output NTSC/PAL

IP Streaming H.264, H.265, MJPEG, NDI|HX, RTMP, RTMPS, RTP, RTSP, SRT, TCP, UDP 1920 x 1080 1280 x 720 640 x 360 320 x 180

Control

Presets 100

Move Speed Pan: 0.08 to 180°/sec Tilt: 0.08 to 180°/sec

Movement Range Pan: 350° (-175 to 175°) Tilt: 120° (-30 to 90°)

Tally Light Yes

Supported Control Protocols RS-422

Interface

Video I/O 1 x HDMI 1.4 Output 1 x USB-C 3.0 / 3.1/3.2 Gen 1 Output

Audio I/O 1 x 1/8" / 3.5 mm TRS Stereo Mic/Line Input

Other I/O 1 x RJ45 (LAN) Control Input 1 x RJ45 (RS-422) Input

Power

PoE Support PoE+ 802.3at

Power I/O 1 x Barrel (10.8 to 13.2VDC) Input

Power Consumption Power Supply: 10.8 to 13.2 VDC at 1.8 A PoE: 42 to 57 VDC at 0.6 A

Environmental

Operating Temperature 32 to 104°F / 0 to 40°C

Storage Temperature -4 to 122°F / -20 to 50°C

Operating Humidity 20 to 90% (Non-Condensing)

General

OS Compatibility Windows 10 to 11 (32/64-Bit) macOS 10.14 to 11.0.1 iOS iPadOS Android *As of December, 2022: Check with manufacturer for the most up-to-date compatibility

Certifications FCC Part 15 Class A *as per Manufacturer

Sound Level NC25

Dimensions (W x H x D) 6.3 x 7.6 x 6.5" / 160 x 192.1 x 166 mm (Without Protrusions, Bracket)

Weight 4 lb / 1.8 kg
