Behringer NX3000 Ultra-Lightweight 3000-Watt Class-D Power Amplifier

Behringer NX3000 Ultra-Lightweight 3000-Watt Class-D Power Amplifier Overview

The Behringer NX3000 is a powerful, efficient 2 RU two-channel Class-D power amplifier designed to deliver high-performance amplification for professional sound systems. With up to 2 x 1600 W peak output at 2 Ohms and 3000 W peak in bridged mode at 4 Ohms, it provides flexible power for a wide range of loudspeaker configurations.

Behringer's SmartSense impedance compensation technology maintains a linear frequency response regardless of speaker load impedance, helping deliver powerful bass, smooth high-frequency reproduction and improved loudspeaker control. A zero-attack limiter provides maximum output while offering reliable overload protection.

The NX3000 uses an ultra-efficient switch-mode power supply and high-density Class-D technology for cool, reliable operation with low power consumption. Built-in crossover functionality provides Full-Range and bi-amp modes, while dual combo XLR-1/4" TRS inputs accommodate balanced or unbalanced sources and professional twist-lock speakON outputs provide secure speaker connections.

Key Features

• Two-channel, 2 RU professional power amplifier

• High-density Class-D amplification for cool, efficient operation

• Up to 2 x 1600 W peak at 2 Ohms

• Up to 2 x 900 W peak at 4 Ohms

• Up to 2 x 440 W peak at 8 Ohms

• Up to 3000 W peak bridged at 4 Ohms

• SmartSense impedance compensation for consistent frequency response

• Zero-attack limiters for maximum output and reliable overload protection

• Ultra-efficient switch-mode power supply

• Built-in stereo crossover with low-cut, high-cut and full-range modes

• Dual mono, stereo and mono bridge operating modes

• Detented and illuminated gain controls

• 4-segment Signal and Limit LED indicators

• Back-to-front ventilation system

Connectivity & Operation

• 2 x combo XLR-1/4" TRS inputs for balanced or unbalanced sources

• Professional twist-lock speakON speaker outputs

• Full-Range mode for unfiltered output

• Bi-amp mode with low-frequency content below 100 Hz directed to passive subwoofers and high-frequency content above 100 Hz directed to full-range speakers

• Independent DC, LF and thermal overload protection on each channel

• Automatic protection helps safeguard the amplifier and connected loudspeakers without interrupting operation

SmartSense Impedance Compensation

SmartSense Technology helps maintain a flat, consistent frequency response across different speaker load impedances. Combined with the NX3000's high damping factor, it provides improved amplifier control over the loudspeaker, particularly at low frequencies, for tighter and more dynamic bass reproduction.
