Yamaha MG16 - 16-Input Mixer

SKU: MG16
Special Order i
Regular price $679.00
Unit price
per

Main Features

  • 10x Mic Inputs
  • 16x Line Inputs
  • XLR and TRS 1/4" Stereo Outs
  • 4x Group Buses
  • TRS Monitor Outs
  • 4x Aux Sends
  • "D-PRE" Mic Preamps with 48V Phantom
  • HPF & 3-Band EQ on Channels 1-8
  • 1/4" Headphone Output with Level Control
  • PAD & 1-Knob Compressor on Channels 1-8
The MG16 from Yamaha is a compact mixer capable of sixteen simultaneous inputs and is ideal for performances, recordings lectures and more. The mixer features eight mono mic/line combo input channels, two stereo line input channels that can also be used as mono mic or...

Yamaha MG16 - 16-Input Mixer

SKU: MG16
Special Order i
Regular price $679.00
Unit price
per
Fast Shipping
Secure payment

4 x

$169.75

from

$10

4 x

$169.75
Tax included.
Write a Review
Ask a Question

Main Features

  • 10x Mic Inputs
  • 16x Line Inputs
  • XLR and TRS 1/4" Stereo Outs
  • 4x Group Buses
  • TRS Monitor Outs
  • 4x Aux Sends
  • "D-PRE" Mic Preamps with 48V Phantom
  • HPF & 3-Band EQ on Channels 1-8
  • 1/4" Headphone Output with Level Control
  • PAD & 1-Knob Compressor on Channels 1-8
The MG16 from Yamaha is a compact mixer capable of sixteen simultaneous inputs and is ideal for performances, recordings lectures and more. The mixer features eight mono mic/line combo input channels, two stereo line input channels that can also be used as mono mic or...
  • What's in the box

    • AC Adapter
    • Rack-Mount Kit
    • Limited 1-Year Warranty

    Yamaha MG16 - 16-Input Mixer

    The MG16 from Yamaha is a compact mixer capable of sixteen simultaneous inputs and is ideal for performances, recordings lectures and more. The mixer features eight mono mic/line combo input channels, two stereo line input channels that can also be used as mono mic or line inputs (XLR and stereo 1/4" inputs), and two stereo line inputs with 1/4" and RCA jacks.

    Channels 1-12 are each equipped with D-PRE mic preamps, 3-band EQ, pan control and a high-pass filter. The D-PRE mic preamps feature an inverted Darlington circuit and switchable 48V phantom power for use with dynamic and condenser microphones. Channels 1-8 each also feature 26dB attenuation switches for use with loud sound sources such as guitar amplifiers and drums.

    The MG16 mixer has XLR and TRS stereo outs for connecting to your PA system or monitor speakers. It also has a 1/4" headphone output with level control for personal monitoring, as well as additional TRS 1/4" stereo monitor outs for sending to powered speakers, amplifiers or devices such as digital recorders.

    • Four TRS auxiliary outputs with dedicated send level control on each channel for routing aux mixes to external devices such as reverb units, monitor mixers and more
    • Four group buses (two stereos) with overall level control fader and dedicated outputs for creating a sub-mix such as a drum group, or for routing separate mixes to amplifiers, powered speakers or other external equipment
    • 3-band EQ on channels 1-8 and 2-band EQ on channels 9-16
    • Pan/balance control on each channel
    • One-knob compressor on channels 1-8 to smooth out the dynamics of vocals and instruments to help them sit better in your mix
    • Rugged metal chassis built to withstand wear and tear
    • Internal universal power supply for worldwide use

What's in the box

  • AC Adapter
  • Rack-Mount Kit
  • Limited 1-Year Warranty

Yamaha MG16 - 16-Input Mixer

The MG16 from Yamaha is a compact mixer capable of sixteen simultaneous inputs and is ideal for performances, recordings lectures and more. The mixer features eight mono mic/line combo input channels, two stereo line input channels that can also be used as mono mic or line inputs (XLR and stereo 1/4" inputs), and two stereo line inputs with 1/4" and RCA jacks.

Channels 1-12 are each equipped with D-PRE mic preamps, 3-band EQ, pan control and a high-pass filter. The D-PRE mic preamps feature an inverted Darlington circuit and switchable 48V phantom power for use with dynamic and condenser microphones. Channels 1-8 each also feature 26dB attenuation switches for use with loud sound sources such as guitar amplifiers and drums.

The MG16 mixer has XLR and TRS stereo outs for connecting to your PA system or monitor speakers. It also has a 1/4" headphone output with level control for personal monitoring, as well as additional TRS 1/4" stereo monitor outs for sending to powered speakers, amplifiers or devices such as digital recorders.

  • Four TRS auxiliary outputs with dedicated send level control on each channel for routing aux mixes to external devices such as reverb units, monitor mixers and more
  • Four group buses (two stereos) with overall level control fader and dedicated outputs for creating a sub-mix such as a drum group, or for routing separate mixes to amplifiers, powered speakers or other external equipment
  • 3-band EQ on channels 1-8 and 2-band EQ on channels 9-16
  • Pan/balance control on each channel
  • One-knob compressor on channels 1-8 to smooth out the dynamics of vocals and instruments to help them sit better in your mix
  • Rugged metal chassis built to withstand wear and tear
  • Internal universal power supply for worldwide use
