Icon ProAudio MicU Live USB Recording Interface

Icon ProAudio MicU Live USB Recording Interface

The Icon ProAudio MicU Live USB Recording Interface provides an audio input and output module as well as analog & digital connectivity with any smart mobile device for live streaming applications.

Main Features Include:

• 24-Bit 192KHz 1 mic-In/1 inst-In, 2-Out USB Recording Interface
• Professional & Hi-end grade DA/AD provides a high dynamic range
  • DAC: Dynamic Range: 114dB
  • ADC: Dynamic Range: 114dB
• Supports Mac/PC connectivity simultaneously with SmartDevice
• Live session possible with audio signal processing via ProDriver4 virtual plug-in rack
• 2×2 analog I/O full-duplex recording and playback
• Compatible with iOS and Android Digital I/O jack (Type C) & Analog I/O jack (3.5mm stereo TRRS)
  for direct connection with a smartphone, tablet or other devices
• Mic/Instrument preamps with individual gain control and phantom power switch
• 2 analog outputs on 1/4” TRS jacks or stereo output on 3.5mm phone connector
• Smartphone input level control on the top panel
• Direct monitor button control on the top panel
• 1 headphone output with assignable source and individual volume control
• ICON ProAudio innovative and user-friendly plug-in hosting rack software is built-in with ProDriver4™
• Flexible channel routing via the ProDriver4 software control panel
• ICON ProAudio developed ultra-low latency ProDriver4™driver is provided
• USB2.0 High Speed equipped and USB bus-powered
• Supports DirectSound, WDM and ASIO2.0
• Compatible with Mac OS (Intel-Mac) 10.11 and later, iOS 9 or above, Android  and Windows 7, 8 & 10 (32-bit/64-bit)
• Full duplex, simultaneous record/playback
• +5VDC power supply connector is equipped for external power supply when using with iOS
• Rugged aluminium construction
