Synology DiskStation DS1823xs+ 8-Bay NAS Enclosure

Synology DiskStation DS1823xs+ 8-Bay NAS Enclosure Overview

The Synology DiskStation DS1823xs+ 8-Bay NAS Enclosure is a powerful desktop storage solution designed for businesses, creative professionals, and IT environments that demand high-performance, scalable, and reliable data management. Combining enterprise-class hardware with Synology's intuitive DiskStation Manager (DSM) operating system, the DS1823xs+ provides a complete platform for centralised storage, file sharing, backup, virtualisation, surveillance, and collaboration.

Powered by a quad-core AMD Ryzen V1780B processor and 8GB of ECC DDR4 memory (expandable to 32GB), the DS1823xs+ delivers impressive sequential read speeds of up to 3,100 MB/s and write speeds of up to 2,600 MB/s. Eight native drive bays support both 3.5-inch and 2.5-inch SATA HDDs and SSDs, while optional SSD caching and all-flash storage configurations help maximise performance for demanding workloads.

Built-in 10GbE networking, three additional Gigabit Ethernet ports, and a PCIe 3.0 expansion slot provide flexible connectivity and future upgrade options, including support for 1/10/25GbE networking and Fibre Channel expansion. Capacity can also be expanded using up to two Synology DX517 expansion units, allowing the system to grow alongside your storage requirements.

Synology DSM offers a comprehensive suite of business applications, including centralised backup, snapshot replication, file synchronisation, virtual machine hosting, surveillance management, and secure collaboration tools. Enterprise features such as Synology High Availability, Active Backup Suite, Hyper Backup, and Snapshot Replication help safeguard critical data while minimising downtime.

Designed for continuous operation, the DS1823xs+ features hot-swappable drive bays, efficient cooling, quiet operation, and advanced power management, making it an ideal solution for organisations seeking dependable, scalable network-attached storage.

Processor

• CPU: Quad-Core AMD Ryzen V1780B
• Clock Speed: 3.35GHz Base / Up to 3.6GHz Boost
• Graphics Processor: None

Memory

• Installed Memory: 8GB ECC DDR4
• Memory Configuration: 1 x 8GB User-Replaceable Module
• Memory Slots: 2
• Maximum Memory: 32GB ECC DDR4

Storage

• Drive Bays: 8 x 2.5"/3.5" SATA III
• M.2 Slots: 2 x M.2 2280 NVMe
• Maximum Capacity: Up to 200TB (With Drives Installed)
• Supported RAID Levels: RAID 0, 1, 5, 6, 10, Basic, Synology F1

Connectivity

• Network Ports: 1 x 10GbE RJ45, 3 x Gigabit Ethernet RJ45
• USB Ports: 3 x USB 3.2 Gen 1 Type-A
• Expansion Ports: 2 x eSATA
• PCIe Slot: 1 x PCIe 3.0 x8 (x4 Electrical)
• Memory Card Slot: None

Networking

• Link Aggregation: Yes
• Failover Support: Yes
• iSCSI Support: 512 LUNs / 256 Targets

Software

• Operating System: Synology DiskStation Manager (DSM)
• Mobile App Support: Android & iOS

Security

• Hardware Encryption: AES-NI
• Security Slot: Kensington Lock Slot
• VPN Connections: Up to 60 (Server)

Power

• Power Input: 100-240V AC, 50/60Hz
• Power Supply: 256W Internal PSU
• Power Consumption: 87.93W (Typical)
• Power Consumption (Standby): 28.37W

Environmental

• Operating Temperature: 0°C to 40°C
• Operating Humidity: 8% to 80%
• Storage Temperature: -20°C to 60°C
• Storage Humidity: 5% to 95%

Physical

• Cooling: 2 x 120mm Cooling Fans
• Noise Level: 23.6 dBA
• Dimensions: 343 x 243 x 166mm
• Weight: 6.2kg

Certifications

• Compliance: BSMI, CCC, CE, EAC, FCC, KC, RCM, RoHS, VCCI
